Bambu Lab PLA Silk+ Filament - Rose Gold
Product Features:
- Shiny Like Chrome, Smooth Like Silk
- Enhanced Layer Adhesion
- A Spectrum of Colors
- Effortless Printing, Flawless Results
- Comes with Basic Reusable Spool
- Diameter: 1.75mm +/- 0.03mm
Cautions for Use:
- Lower the outer wall speed to 50 mm/s for the best gloss
- Dry Out Before Use
- AMS & AMS lite Compatible
Why choose between beauty and durability? Bambu PLA Silk+ delivers both with its impressive strength, while still offering a stunning silk gloss finish. Available in a wider range of vibrant colors, this filament lets you bring your boldest ideas to life without compromising on toughness or shine. With Bambu PLA Silk+, you can have it all, strength, style, and performance.
Shiny Like Chrome, Smooth Like Silk
Bambu PLA Silk+ features an enhanced sheen and gloss. Making it ideal for creating models that require a luxurious silk or metallic finish, this filament elevates your printing projects to a new level. Experience the pinnacle of silk printing with Bambu PLA Silk+!
Enhanced Layer Adhesian
No need to make any trade-offs between layer adhesion and appearance.* Bambu PLA Silk+ is engineered for strength, providing enhanced layer adhesion and performance. With superior resistance to bending and impact, Bambu PLA Silk+ ensures your creations stand the test of time.
3D Printed PLA Silk+ Examples
A Spectrum of Colors
Bambu PLA Silk+ presents a stunning array of vibrant color options to suit all your creative needs. Notably, Candy Green and Candy Red are specifically designed for Christmas décor, allowing you to celebrate the holidays with your unique touch!
Effortless Printing, Flawless Results
Bambu PLA Silk+ streamlines your printing process with a silk-smooth experience. Its advanced formulation ensures you achieve perfect results with ease, allowing you to focus on creativity without the hassle. Elevate your projects with a smoother, more efficient printing experience today!
RFID for Intelligent Printing
All printing parameters are embedded in RFID, which can be read through our AMS (Automatic Material System). Load and print! No more tedious setting steps.
Specifications
| Recommended | Not Recommended | |
|---|---|---|
| Build Plate | Cool Plate SuperTack Smooth PEI Plate Textured PEI Plate |
– |
| Hotend | Hardened Steel Nozzle 0.4 mm Stainless Steel Nozzle 0.2 mm / 0.4 mm |
Hardened Steel Nozzle 0.6 mm / 0.8 mm |
| Glue | Bambu Liquid Glue | Glue Stick |
| AMS & AMS lite | AMS & AMS Lite | – |
PLA Silk+ Hex Code Table
| Color Name | Hex Code | Display |
|---|---|---|
| Gold | #F4A925 | |
| Silver | #C8C8C8 | |
| Titan Gray | #5F6367 | |
| Blue | #008BDA | |
| Purple | #8671CB | |
| Candy Red | #D02727 | |
| Candy Green | #018814 | |
| Rose Gold | #BA9594 | |
| Baby Blue | #A8C6EE | |
| Pink | #F7ADA6 | |
| Mint | #96DCB9 | |
| Champagne | #F3CFB2 | |
| White | #FFFFFF |
| Recommended Printing Settings | Physical Properties | Mechanical Properties | |||
|---|---|---|---|---|---|
| Drying Settings (Blast Drying Oven) | 55 °C, 8 h | Density | 1.27 g/cm³ | Tensile Strength | 33 ± 4 MPa |
| Printing and Keeping Container's Humidity | < 20% RH (Sealed, with Desiccant) | Vicat Softening Temperature | 66 °C | Breaking Elongation Rate | 2.8 ± 0.6% |
| Nozzle Temperature | 210 - 240 °C | Heat Deflection Temperature | 60 °C | Bending Modulus | 2460 ± 150 MPa |
| Bed Temperature (with Glue) | 35 - 45 °C | Melting Temperature | 158 °C | Bending Strength | 75 ± 4 MPa |
| Printing Speed | < 250 mm/s | Melt Index | 14.5 ± 1.2 g/10 min | Impact Strength | 18.5 ± 1.6 kJ/m² |
Printing Tips
1. To enhance the gloss of your print’s appearance, it’s recommended to slow down the Outer wall printing speed. No need to worry about the reduced adhesion found in generic PLA Silk—Bambu PLA Silk+’s improved layer bonding fully supports this adjustment.
2. Dry before use to ensure the best print quality and consistent finish. Drying conditions: In a blast drying oven: 55°C for 8 hours; On an X1 printer's heatbed: 65°C to 75°C for 12 hours. Store in a dry environment after use.
3. Concentric top surface pattern can optimize the print quality of top shells
