Snapmaker Artisan 3-in-1 3D Printer (Pre-Order ETA Early May)

$ 2,999.00

-
+
$ 2,999.00
Snapmaker Artisan 3-in-1 3D Printer

Snapmaker Artisan 3-in-1 3D Printer

Turn Your Desktop Into a Workshop

THIS PRODUCT IS IN PRODUCTION. ESTIMATED AVAILABILITY EARLY MAY

Snapmaker Artisan, the ultimate 3-in-1 3D printer that is larger, stronger and more accessible than ever. This dual extrusion 3D printer boasts 300°C capabilities and also doubles as a high-power laser engraver and cutter, as well as a CNC carving and cutting machine with 200W power. Artisan's linear modules are powered by industrial-grade transmission technology, providing precision and accuracy in your projects.

With a large 400 x 400 x 400 work area and quick-swap toolheads, platforms, and hot ends, it is easy to switch between functions. Powered by Snapmaker's free 3-in-1 software, Snapmaker Luban, offers a plethora of design and editing tools to create and customize your projects. Artisan's all-metal design and laser-proof enclosure provide both durability and safety. Artisan is the perfect tool for makers and creators who want to bring their projects to life. Don't wait any longer, unlock your creative potential with the Snapmaker Artisan.

Next-Gen

Linear Modules

400 × 400 × 400

Work Area

1 Min

Quick-swap

300°C

Dual Extrusion

10W

Laser

200W

CNC


Industrial-grade Transmission Technology

Steel guiderails made by CNC grinding at micron level are embedded in Artisan's linear modules, leading to a significant raise in precision, rigidity and durability.

snapmaker artisan industrial grade linear rails 3d printer

400 × 400 × 400 Work Area

Create big or multiple objects as you please in 400 mm × 400 mm × 400 mm large work area.

snapmaker artisan large build volume
snapmaker artisan large 3d print

3D Printing

snapmaker artisan laser cutter leather work

Laser Cutting

snapmaker artisan cnc wood work

CNC Cutting

1 Min Quick Swap

Quick-swap platforms and toolheads let you shift among 3 functions in 1 minute.

Platforms

Toolheads

Fast and Well

Thanks to the optimized transmission system and motion control algorithm, Artisan features ± 0.1 mm dimensional accuracy when printing at a high speed of 180 mm/s.

Fine

40 mm/s Printing Speed

800 mm/s² Acceleration

0.12 mm Layer Height

Normal

80 mm/s Printing Speed

1,000 mm/s² Acceleration

0.16 mm Layer Height

Fast

120 mm/s Printing Speed

1500 mm/s² Acceleration

0.20 mm Layer Height

Extra Fast

200 mm/s Printing Speed

2000 mm/s² Acceleration

0.24 mm Layer Height


1.6W and 10W Laser Comparison.

The 10W Laser Module can engrave at a speed as high as 6000 mm/min, while cutting through wood as thick as 8 mm in a single pass. To put that into perspective, the cutting speed is up to 8 times that of the 1.6W Laser Module.

snapmaker artisan Engraving Speed 10W

Toolheads

Engraving Speed (1.5 mm basswood)

snapmaker Artisan engraving speed

Cutting Speed (1.5 mm basswood)

snapmaker Artisan cutting speed

Max Cutting Depth (Paulownia)

snapmaker Artisan cutting depth speed

6X Faster CNC Machining.

Compared with Snapmaker 2.0, the CNC module of Artisan has increased by 300% in power and 50% in maximum spindle speed, making it 6 times faster in machining on hardwood like beech.

snapmaker artisan cnc module

Toolheads

Power

snapmaker Artisan engraving speed

Max. Spindle Speed

snapmaker Artisan cutting speed

Max. Recommended Machining Speed for Beech

snapmaker Artisan cutting depth speed

Snapmaker 2.0 Comparison

  A350T/A250T Artisan
Standard 3D Printing Module Single Extrusion Dual Extrusion
Standard Laser Module 1600mW 10W
Standard CNC Module 50W 200W
Enclosure Included X
Built-in Emergency Stop Button X
Quick-swap Design X
Touchscreen Display 5 inch 7 inch
Machine Dimensions
(W × D × H)
495 mm × 506 mm × 580 mm/
405 mm × 424 mm × 490 mm
580 mm × 620 mm × 634 mm
Enclosure Dimensions
(W × D × H)
820 mm × 626 mm × 603 mm/
624 mm × 530 mm × 507 mm
665 mm × 943 mm × 705 mm

Specifications

General

Dimensions (Machine)

580 mm × 620 mm × 634 mm

snapmaker demensions

Dimensions (Machine & Enclosure)

665 mm × 943 mm × 705 mm

snapmaker demensions

Weight

116.6 lbs (52.9 kg)

Package Weight

Box A: 76.7 lbs (34.8 kg)
Box B: 69.4 lbs (31.5 kg)

Supported Software

Snapmaker Luban, and third-party software

OS Supported by Luban

Windows, macOS, Linux

Data Transmission Methods

Wi-Fi, USB cable, USB flash drive

Extruder System

Independent Dual Extruders (IDEX)

General

Dimensions

189 mm × 300 mm × 191 mm

snapmaker demensions

Touchscreen Size

7 inches

Power

300W + 450W

OS

Android

3D Printing

Work Area (W × D × H)

350 mm × 400 mm × 400 mm (Dual Nozzle)

Dimensional Accuracy

± 0.1 mm

Nozzle Diameter (Standard)

0.4 mm

Nozzle Diameter (Optional)

0.2 mm, 0.6 mm, 0.8 mm

Nozzle Material (Standard)

Brass

Nozzle Material (Optional)

Hardened steel

Max. Nozzle Temperature

300°C

Max. Recommended Printing Speed

180 mm/s

Build Plate

Double-sided PEI-coated Glass

High-temperature Zone (Inner Zone)

260 mm × 260 mm

Max. Heated Bed Temperature (Inner Zone)

110°C

Max. Heated Bed Temperature (Outer Zone)

80°C

Supported Materials

PLA, ABS, ASA, PETG, TPU, Breakaway PLA, PVA, HIPS, Nylon, Carbon Fiber Reinforced Nylon, Glass Fiber Reinforced Nylon

Supported Formats

stl, obj

Laser Engraving and Cutting

Work Area (W × D)

400 mm × 400 mm

Power

10W

Laser Type

450 nm–460 nm Semi-conductor

Max. Engraving Speed

100 mm/s

Max. Cutting Depth (Paulownia)

8 mm

Operating Temperature

0°C–35°C

Laser Spot Dimension

0.05 mm × 0.2 mm

Supported Materials for Engraving

Basswood, Paulownia, Pinewood, Plywood, Beech, Walnut, Bamboo, MDF, Painted Metal, Copper Clad Laminate, Tinplate, Stainless Steel, Anodized Aluminum, Dark Glass, Slate, Ceramics, Jade, Marble, Shale, Leather, Fabric, Canvas, Corrugated Paper, Cardboard, Plastic, Dark Acrylic (Blue excluded)

Supported Materials for Cutting

Basswood, Paulownia, Pinewood, Plywood, Beech, Walnut, Bamboo, MDF, Leather, Fabric, Canvas, Corrugated Paper, Cardboard, Plastic, Dark Acrylic (Blue excluded)

Supported Formats

stl, svg, png, jpg, jpeg, bmp, dxf

CNC Carving and Cutting

Work Area (W × D)

400 mm × 400 mm

Power

200W

Max. Spindle Speed

18,000 RPM

Max. Work Speed

50 mm/s (Beech); 33 mm/s (Acrylic)

Maximum Stepdown

2 mm (Beech); 1 mm (Acrylic)

Shank Diameter

0.5 mm–6.35 mm

Supported Materials

Hardwood (Beech, Walnut), Softwood, HDF, MDF, Plywood, Jade, Carbon Fiber, Acrylic, Epoxy Tooling Board, PCB

Supported Formats

stl, svg, png, jpg, jpeg, bmp, dxf

In the box

Box A:

Integrated Controller × 1

Dual Extrusion Module × 1

10W Laser Module × 1

200W CNC Module × 1

Toolhead Quick-swap Bracket × 1

Tool Box × 1

Z-axis Linear Module × 2

X-axis Linear Module × 1

Y-axis Linear Module × 2

Base Plate × 1

AC Power Cable × 1

USB Cable × 1

Filament Tube × 2

Filament Tube Holder × 2

M4 Wing Nut × 4

Cable Clip × 3

Filament Tube Clip × 2

L Bracket × 1

Filament Holder Base × 2

Toolhead Cable × 1

Heated Bed Cable × 1

Enclosure Cable × 1

Cable Collector × 1

Hose × 1

Hose Clamp × 1

Base Fixture x 2

Cable Pass-through Fixture × 1

Laser Material Fixture × 4

Sealing Plug × 4

Sealing Strip × 1

Filament Holder Tube × 2

CNC Safety Goggles × 1

Calibration Card × 1

Quick Start Guide × 1

Wiping Cloth × 1

Enclosure Screws

Machine Screws

Box B:

Side Panel × 2

Door Panel × 1

Top Panel Kit × 1

Back Panel × 1

Exhaust Fan × 1

Hose Connector × 1

Column-1 (with hinge) × 1

Column-2 (with hall switch) × 1

Column-3 (with Enclosure converter) × 1

Column-4 × 1

Beam × 4

Profile Connector × 41

Door Handle × 1

Auxiliary Board × 1

Laser Engraving and Cutting Platform × 1

CNC Carving and Cutting Platform × 1

3D Printing Platform × 1

Support Platform × 1

X-axis Connector × 2

Z-axis Holder × 2

White Breakaway Filament × 1

Black PLA Filament × 1

HDF Sheet × 1

Basswood Sheet × 1

Cord Collecting Strip × 1

Manufacturer Part Number: 81012
